Ricoh SP 6430DN - Page 103

7. Pull the fusing unit out.
DBQ023
8. Hold the tab, and then remove the jammed paper.
DBQ073
9. If the paper is not jammed in the fusing unit, remove the jammed paper from inside of the
printer.
DBQ074
Removing Jammed Paper
101
