Problem Solutions
Attached options are not
detected in the printer
properties.
The computer and printer are not in bidirectional
communication. You must configure attached options in the
printer properties. For details, see the printer driver's Help.
Once you perform an automatic update of device information
using the PCL 6 or PostScript 3 printer driver's properties,
other printer drivers may not be able to establish a
bidirectional communication and cannot perform the
automatic update successfully. This only occurs with 32-bit
Windows XP. In such cases, log off and log back on to
Windows, and perform the automatic update again. If the
problem cannot be resolved, contact your sales or service
representative.
When printing combined prints
or bound prints.
Check that the paper size and direction set in the printer driver are
the same as those set in the application.
If the settings are not the same, change the settings of the printer
driver.
An empty tray is selected by
Auto Tray Select, and the
document is not printed due to
out of paper error.
If a paper tray is opened and closed while the printer is in Energy
Saver mode, the printer will initialize the tray upon recovery, but
the tray will not be selectable by Auto Tray Select.
To print from a paper tray that you opened and closed while the
printer was in Energy Saver mode, you must manually specify the
tray as the source paper tray before printing. When the printer
recovers from Energy Saver mode and completes initialization, it
will then print the document from the tray you have specified.
Other Printing Problems
91

Table of Contents

Other manuals for Ricoh SP 6430DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 6430DN and is the answer not in the manual?

Ricoh SP 6430DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)38 ppm
Printing colorsBlack
Maximum duty cycle150000 pages per month
Number of print cartridges1
Page description languagesPCL 5c, PCL 6, PostScript 3
Paper input typePaper tray
Total input capacity600 sheets
Total output capacity500 sheets
Maximum input capacity2100 sheets
Maximum print size297 x 432 mm
Duplex media weight56 - 162 g/m²
Paper tray media typesEnvelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper, Transparencies
Paper tray media weight56 - 220 g/m²
Duplex media weight (imperial)15 - 43 lbs
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)15 - 59 lbs
Mobile printing technologies-
Standard interfacesEthernet, USB 2.0
Maximum internal memory1024 MB
DisplayLCD
Product colorGrey, White
Display number of lines4 lines
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.45 W
Power consumption (printing)554 W
Sustainability certificatesENERGY STAR
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003 R2, Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width459 mm
Height347.5 mm
