Ricoh SP C252DN

6. Close the bottle cap.
DAC083
DAC082
7. Holding the center of the new waste toner bottle, carefully insert it halfway into the
machine body.
Leave the bottle cap open.
DAC079
To prevent the waste toner bottle from coming into contact with the intermediate transfer unit (the
position shown by the arrow in the illustration below), do not lift the bottle while inserting it.
Replacing the Waste Toner Bottle
137
