Page #73 background imageLoading...
Page #73 background image
Message Cause Solution
"IPv6 Address already exists
Manual Config.
Address(109/209)"
The same IPv6 address is already
used.
Contact your network
administrator.
"Load paper in (tray name)
or [Cancel] to FormFeed."
There is no paper in the specified
tray.
Load the specified paper in the
tray, press [JobReset] to reset the
job. To print from the bypass tray
on paper whose width is less than
84 mm, cancel the print job, and
then, under [System], set [Bypass
Print: 64-84 mm] to [Active].
"May have exceeded max
no. of prints in output tray.
Print stopped. Check the
tray."
The output tray is full. Remove paper from the output
tray.
"Output Tray is full. Remove
paper."
The output tray is full. Remove the paper.
"Problem: Printer Font Error" There are problems with the
printer's font file.
Turn the printer off, and then turn it
on again.
If the problem persists, contact
your sales or service
representative.
"Problem:Wireless board
Please call service."
The printer cannot detect a
wireless LAN interface board.
Check that the wireless LAN
interface board installed correctly.
If the problem persists, contact
your sales or service
representative.
"Replace Fusing Unit." You will need to replace the
fusing unit soon.
Contact your sales or service
representative to obtain a new
unit.
"Replacemnt
Requird:IntTrans"
You need to replace the
intermediate transfer unit.
For details, see "Replacing Other
Consumables", Operating
Instructions.
"Replcmnt Requrd: Print
Cart"
The toner has run out, or the
photo conductor unit has reached
the end of its service life.
For details, see "Replacing the
Print Cartridge", Operating
Instructions.
When Messages Are Displayed
71

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP C340DN and is the answer not in the manual?

Ricoh SP C340DN Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)13.5 s
Print speed (black, normal quality, A4/US Letter)- ppm
Duplex print speed (black, normal quality, A4/US Letter)25 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle75000 pages per month
Number of print cartridges-
Page description languagesPCL 5c, PCL 6, PostScript 3
Total input capacity600 sheets
Total output capacity150 sheets
Maximum input capacity1100 sheets
Paper tray media typesCoated paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Security algorithmsSNMP, SSL/TLS
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Processor familyIntel Atom®
Sound power level (standby)31 dB
Sound pressure level (printing)65 dB
DisplayLCD
Product colorGray
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1300 W
Power consumption (standby)0.5 W
Power consumption (printing)- W
Power consumption (PowerSave)65 W
Energy Star Typical Electricity Consumption (TEC)1.6 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Sustainability certificatesENERGY STAR
Storage temperature (T-T)30 - 40 °C
Storage relative humidity (H-H)0 - 80 %
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth480 mm
Width400 mm
Height387 mm
