Ricoh SP C340DN User Manual

Message Cause Solution
"Replacmnt Rqrd:Fusing
Unit"
You need to replace the fusing
unit.
For details, see "Replacing Other
Consumables", Operating
Instructions.
"Replcmnt Rqrd
Soon:IntTrans"
You will need to replace the
intermediate transfer unit soon.
Contact your sales or service
representative to obtain a new
unit.
"Repl Requrd
Soon:FusingUnit"
You will need to replace the
fusing unit soon.
Contact your sales or service
representative to obtain a new
unit.
"Sensor cleaning required." You need to clean the toner
density sensor.
For details, see "Cleaning the
Toner Density Sensor", Operating
Instructions.
"Set the Fusing Unit
correctly."
The fusing unit may not be
installed correctly. Turn the printer
off and re-install the fusing unit.
If the message is still displayed
after re-installation, contact your
sales or service representative.
For details, see "Replacing Other
Consumables", Operating
Instructions.
"Set the Intermediate
Transfer Unit correctly."
The intermediate transfer unit may
not be installed correctly. Turn the
printer off and re-install the
intermediate transfer unit.
If the message is still displayed
after re-installation, contact your
sales or service representative.
For details, see "Replacing Other
Consumables", Operating
Instructions.
"Set the Print Cartridge
correctly."
The print cartridge may have not
been installed correctly.
Turn the printer off, and install the
print cartridge again.
"Set Waste Toner Bottle
correctly."
The waste toner bottle may not be
installed correctly. Turn the printer
off and re-install the waste toner
bottle.
If the message is still displayed
after re-installation, contact your
sales or service representative.
For details, see "Replacing Other
Consumables", Operating
Instructions.
3. Troubleshooting
72

Ricoh SP C340DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	13.5 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Duplex print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PostScript 3
Total input capacity	600 sheets
Total output capacity	150 sheets
Maximum input capacity	1100 sheets
Paper tray media types	Coated paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	SNMP, SSL/TLS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	Intel Atom®
Sound power level (standby)	31 dB
Sound pressure level (printing)	65 dB
Display	LCD
Product color	Gray
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1300 W
Power consumption (standby)	0.5 W
Power consumption (printing)	- W
Power consumption (PowerSave)	65 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	30 - 40 °C
Storage relative humidity (H-H)	0 - 80 %
Cables included	AC

Weight and Dimensions

Depth	480 mm
Width	400 mm
Height	387 mm
