Intermediate Transport Sensor Left
1. Proof tray (page 13)
2. Intermediate transport sensor left [A] ( ×1, ×1, ×1)
Shift Tray Paper Surface Sensor
1. Left center cover (page 15)
1. Replacement and Adjustment
22
