Ricoh SR3150 - Jogger Motor; Paper Bundle Transport Upper Pressure Release Motor

2. Separate the jogger fence [A] from the jogger HP sensor [B].
3. Jogger HP sensor ( ×1)
• Release and remove the claw with a small driver, etc.
Jogger Motor
1. Stapler tray (page 29)
2. Jogger motor [A] ( ×2, ×1)
Paper Bundle Transport Upper Pressure Release Motor
1. Stapler tray (page 29)
1. Replacement and Adjustment
34
