2. Shift motor [A] ( ×2, x1)
Paper Eject Transport Motor
1. Rear cover (page 9)
2. Paper eject transport motor [A] ( ×2, ×1)
Paper Bundle Transport Upper Motor
1. Rear cover (page 9)
1. Replacement and Adjustment
26
