Ricoh SR3150 - Center-Folding Unit

6. Booklet stapler unit ( ×2)
• When you remove the booklet stapler unit from the main frame, be careful not to catch the cable
on the frame.
Center-Folding Unit
1. Booklet stapler unit (page 45)
2. Knobs [A] ( ×2)
1. Replacement and Adjustment
46
