bit1 1
9. Push [#Enter] to set "1" for Bit SW 1.
10. After setting Bit 1 to "1", push [Escape] until the display returns to "ENGINE MAINTE."
11. At "3. END" press [#Enter] to leave the SP mode.
12. Push [Menu] then select "Maintenance"> "3. Head-Flushing".
13. Select the one print head (or all) for drive cleaning and push [#Enter].
• The print head is flushed. In addition to flushing, drive cleaning is also performed with the piezo
element switching on and off..
• Once drive cleaning is completed for the selected print head, Bit 1 resets to "0" automatically.
• If you need to do this procedure again for another print head, you must repeat this procedure
and set Bit 1 to "1" again in the SP mode.
• Drive cleaning cannot be performed if the ink tank of the selected print head is almost empty.
Drive Cleaning Procedure
55
