2.8 Spoke Tension:
3. Battery Connection & Removal
• Insert the key into the battery keyhole.
• Turn the key in a clockwise direction (At 90 degrees).
• Pull out the battery.
• Replace battery with key in the same position, then turn the key to lock. This model’s battery lock
automatically returns to the locked position.
NOTE: ◆ ALWAYS KEEP THE CHARGE PORT COVERED TO PROTECT AGAINST MOISTURE, WHICH
CAN DESTROY THE BATTERY. THIS IS ESPECIALLY IMPORTANT IF YOU LIVE IN A WET CLIMATE.
4. Charging the Battery:
WARNING ◆ DO NOT LEAVE CHARGING BATTERY UNATTENDED
The battery’s voltage is indicated by the 4 LED lights located on the top of the battery, and also on the
display unit located on the handlebars. Battery Level is indicated using 3 different colors; Blue when full,
Green when half or less than full, red when low battery. Your battery must be charged in an ambient
temperature, on a non-flammable & dry surface, away from any sources of heat, humidity or flammable
materials. Also, it must not be covered.
Follow the steps when charging battery:
Step 1. Turn the bike off. The LCD will be off.
Step 2. Plug the charger (which is off) into the socket and then insert the charger plug into the battery.
• The red LED lights on: The battery is being charged. ( A )
• The red LED light becomes green: The battery is fully charged, and you can unplug the charger.
(Figure B)
