2.3 Seat Post Assembly:
• Open the seat clamp and insert the seat post. (Figure 8 & 9)
• Adjust the suitable height and rotate the clamp to tighten and then shut it. (Figure 10)
2.4 Seat Clamp Assembly:
• Slide saddle into seat post clamp.
• Using a 6mm hex wrench. Tighten the bolt to 16-17nm of torque.
• The seat post angle is adjustable. Ensure the bolt is correctly torqued. If left loose or over-
tightened, the seat post bolt could snap.
NOTE: ◆ SOME GENERATIONS COME WITH THE SEAT POST SEPARATE FROM THE SADDLE.
IF ALREADY JOINED, CHECK THAT THE TORQUE ON THE BOLT IS TO 16-17 NM SPEC.
