10
3.2 Saddle/Seat Post Assembly:
• Open the seat clamp and insert the seat post to or past the minimum insertion point. (Figure 5 & 6)
• Adjust the suitable height and rotate the clamp to tighten and then shut it. (Figure 7)
3.3 Seat Clamp Assembly:
• Slide saddle into seat post clamp.
• Using the provided hex wrenches, tighten the bolts to the torque specs marked on the seat post.
• The seat post angle is adjustable. Ensure each bolt is correctly torqued. If left loose or over-tightened,
a seat post bolt could snap.
5
6
7
