WARNING:
◆
IT’S VITAL TO TIGHTEN THE BAR CLAMP TO AVOID THE MOVEMENT OF THE
HANDLEBARS, AS WELL AS THE COMPRESSION CAP, ENSURING FORK IS INSTALLED CORRECTLY. THIS
SHOULD BE COMPLETED BY SOMEONE FAMILIAR WITH BIKE MECHANICS
3.2 Front Wheel Assembly:
• Do not touch the brake pads or brake rotors with your fingers. The oil will contaminate them
and cause noises when braking.
• Do not squeeze the brake lever before the rotor is installed in between the brake pads. This
may damage the brake caliper.
• Do not stress, stretch, or kink your hydraulic brake line.
• Align the disc rotor so it fits between the brake pads. Do not force it. (Figure 2)
• Place the front wheel axle onto the fork dropouts. (Figure 3)
