IF the inrush lasts less than the Delay time and then falls below the OCP value, the unit
will continue to operate like a normal CV Mode only Power Supply.
However, IF the current draw climbs back above the OCP value:
● The RD60xx will NOT go into CC Mode.
● The RD60xx WILL go into Protection Mode after the response delay
Special Notes:
- This option is for ADVANCED USERS ONLY.
- Improper use could result in Equipment or Personal Damage.
- Ensure you understand how this option works before use.
- To enable this option, the ‘ON-CODE’ value MUST be set to 11235.
(Hint to remember the code: Fibonacci Sequence)
Any other value will result in the option being set to OFF.
- On Testing, the Delay is typically around 250ms, but has been measured up to
600ms.
IVSet Timeout
➥Appearance
OFF: IVSet Timeout is NOT enabled.
Settable Range: 00m 01s - 99m 59s
Determines if, and for how long, the unit will wait for data entry when setting a value using the
“I-SET” or “V-SET” buttons.
This applies for setting the Voltage, Current, OVP, OCP, or OPP values.
IF Set:
● The timer will reset on any data entry, except “ENTER”.
○ Pressing “ENTER” will apply the current setting.
● The value displayed at the end of the timeout timer will automatically be applied.
Key Beep
➥Buzzer
ON Buzzer sounds once when any button(s) is pressed.
OFF Buzzer does NOT sound when button(s) pressed.
LOCK
Can Only be Enabled by Panel buttons “SHIFT” + “●”
When enabled, physical buttons and encoder knob have no affect.
