Riden RD6012 - Detailed Setting Options Explained

18
14. Description of Each Setting’s Options
Address
➥Communication
Settable Range: 001 - 255
Used to uniquely identify unit when multiple devices connected
AutoPowerOff
➥Power Settings
Settable Range: Never / 00h01m - 59h59m
Automatically Power off after specified time IF RD60xx unit is in idle mode.
Idle mode = output off, no user interaction, no communication.
Any user input or external communication will reset the timer.
AutoPwrOffBeep
➥Buzzer
If AutoPowerOff Enabled:
ON Buzzer will sound when AutoPowerOff activated (timer reaches 0).
OFF Buzzer will NOT sound when AutoPowerOff activated.
Backlight
➥Display
Settable Range: 0 - 5
Screen Brightness Selection. Higher setting is brighter.
Boot Logo
➥Display
ON Display Logo/Splash screen on Boot-up.
OFF Enter the main page directly.
Instructions for How to Change the Boot Logo Image.
