Max Power
➥Power Settings
Settable Range: Up to Maximum Power Rating of the unit.
RD6006: 360W
RD6012: 720W
RD6018: 1080W
Limits output power to set value.
- Protects the primary power supply if not capable of providing full power of RD60xx.
Manufacturer recommended setting:
No higher than 95% of the rated power for the Primary Power Supply.
Example:
IF using a 800W primary supply on an RD6018,
Set the ‘Max Power’ value no higher than:
800W x 0.95 = 760W
Mem Hint
➥Appearance
OFF Memory Hint will not be displayed.
Value Time, in seconds, that the Memory Hint will be displayed.
When enabled,
Pressing a memory location number (“M1” - “M9”) will display the values stored at
that location for the time set.
Pressing the same button again (double press) will apply the settings.
Mute
➥Buzzer
ON Buzzer functions as set by the other Buzzer Group settings.
OFF Buzzer does NOT sound, regardless of other settings.
