Status Info
➥Appearance
Default Cycles through Ah, Wh, and Sys Temp. (see below)
Empty Do NOT show any Status data.
Ah Amp Hours accumulated - From Battery Charging Mode.
Wh Watt Hours accumulated - From Battery Charging Mode.
V-BATT Battery Voltage - Only displayed if a battery is connected.
T-BATT External Temperature Value - Only displayed if a battery is connected.
Sys Temp. Internal Temperature Value.
Ah + Wh Ah and Wh metrics from Battery Charging mode.
t° INT + EXT Internal and External Temperature Values.
ORP + Ω ‘ORP’ setting value and current Load resistance measurement.
ADC V/I Raw ADC value of Voltage and Current measurements.
ADC IN/BA Raw ADC value of Input (From Primary Supply) and Battery.
ADC Temp. Raw ADC value of Internal and External Sensor values.
Notes:
Raw ADC values can be used for calibration purposes.
See ‘Raw ADC Values and Calibration’ section for more detail.
t° -EXT icon
➥Appearance
ON Battery Charging icon will include the value from the External Temperature Probe.
OFF Battery Charging icon will not include temperature.
Example Icons:
OFF ON
Take Ok
➥Appearance
When recalling settings from a Memory Location
ON Pop-up confirmation window - before changing settings
OFF Settings Modified Immediately - without confirmation.
Take Out
➥Appearance
When recalling settings from a Memory Location
ON Output will turn ON automatically when memory Selected/Recalled.
OFF Output Maintains existing ON/OFF status.
