RIDGID 1233 - Specifications

Figure 1 – 300 Compact Threading Machine
Figure 2 – 1233 Threading Machine
5
300 Compact/1233 Threading Machines
Rear
Centering
Device
REV/OFF/FWD
(2/0/1)
Switch
Motor
Cover
Hand
Hold
Chip Tray
Chuck Jaw
Handwheel
Carriage
Handwheel
Front
Hand
Hold
Quick Opening
Die Head
Cutter
Reamer
Rear
Centering
Device
REV/OFF/FWD
(2/0/1)
Switch
Warning
Label
Die
Head
Chip
Tray
Chuck Jaw
Handwheel
Carriage
Handwheel
No. 743
Reamer
No. 763
Cutter
Specifications
Parameter 300 Compact Threading Machine 1233 Threading Machine
Pipe Threading Capacity
1
/
8
to 2 inch (3 to 50 mm)
1
/
8
to 3 inch (3 to 80 mm)
(Nominal Pipe Size)
Bolt Threading Capacity
1
/
4
to 2 inch (6 to 50 mm)
3
/
8
to 2 inch (9,5 to 50 mm)
(Actual Stock Diameter)
Yes No
LH Threads (units with REV only)
Rated Motor Power (HP)
1
/
2
HP (0.37 kW)
1
/
2
HP (0.37 kW)
Motor Type Universal Motor, Single Phase Universal Motor, Single Phase
Electrical Information 36 RPM 52 RPM 115 V, 50/60 Hz, 15 AMP
115 V, 50/60 Hz, 12 AMP 115 V, 50/60 Hz, 18 AMP 230 V, 50/60 Hz, 8 AMP
230 V, 50/60 Hz, 8 AMP
1700 W 2100 W 1700 W
Operating Speed 36 RPM (52 RPM version available) 36 RPM
Rotary Type REV/OFF/FWD (2/0/1) switch Rotary Type REV/OFF/FWD (2/0/1) switch
Controls and ON/OFF foot switch, and ON/OFF foot switch
Some units use an OFF/ON Rocker Some units use an OFF/ON Rocker
Switch in place of the Rotary Switch. Switch in place of the Rotary Switch.
Front Chuck Hammer-Type with replaceable Hammer-Type with replaceable
Rocker-Action Jaw Inserts Rocker-Action Jaw Inserts
Rear Centering Device Scroll operated, rotates with Chuck Scroll operated, rotates with Chuck
Die Heads See RIDGID Catalog for available Die Heads See RIDGID Catalog for available Die Heads
Cutter Model 360,
1
/
8
" - 2" Full Floating, Model 763,
1
⁄
4
" - 3",
Self Centering Cutter Self Centering Cutter
Reamer Model 344,
1
/
8
" - 2" Reamer Model 743,
1
⁄
4
" - 3", 5-Fluted Reamer
Oil System Reservoir Capacity 3.2 qt (3 l), Reservoir Capacity 3.2 qt (3 l),
with integrated Gerotor Pump, with integrated Gerotor Pump,
adjustable flow rate adjustable flow rate
Weight (Unit with Die Head) 141 lb (64 kg) 165 lb (75 kg)
Warning
Label
Warning
Label
Foot
Switch
Oil
Drain
Carriage
Warning
Label
Foot
Switch
Oil
Drain
Motor
Cover
Carriage
