Repair Parts
Parts List For RIDGID Oscillating Edge Belt/ Spindle Sander
Model EB44241
RIDGID parts are available on-line at www.ridgidparts.com
Figure 2
Always order by Part Number—Not by Key Number
* Standard Hardware Item - May be purchased locally
2
5
6
9
10
11
12
14
15
16
7
1
3
4
4
4
18
17
8
19
13
8
2
19
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
825539
830306
830453
37482
830305
825531
825529
805549-4
830304
826163-2
830454
Knob 10-32 x 1-1/4
Washer 12 mm 1.0.
Drum/Drive Asm.
Nut, Lock
Guide
Spring, Extension
Lever
* Washer
13/64 x 1/2 x 3/64
Shaft, Idle
Cap, Grip
Drum, Idle Asm
Key
No.
Part No. Description
12
13
14
15
16
17
18
19
817453
826802
30521
821166-1
809169-9
820175
9416712
114603
Ring, Retaining 5160-50
Platen
Spring, Swivel
Screw, Flat Hd Hex
10/32 x 1-1/2
Screw, Pan Cr Ty T
8-32 x 3/4
Washer, Rubber
* Washer
3/16 x 5/8 x 1/16
* Lockwasher, Ext. #10
