gloves� Do not use damaged drain cleaning gloves�
• Practice good hygiene. Use hot, soapy water to
wash hands and other body parts exposed to drain
contents after handling or using drain inspection
equipment� To prevent contamination from toxic or in‑
fectious material, do not eat or smoke while operating
or handling drain inspection equipment�
The information supplied with this product cannot
cover all possible conditions and situations that may
occur, and should be used in conjunction with appro-
priate training, sound judgment, and good work prac-
tices. These factors cannot be built into the product,
but must be supplied by the operator.
The EC Declaration of Conformity (890‑011‑320�10) will
accompany this manual as a separate booklet when re‑
quired�
Description, Specications, and
Standard Equipment
Description
The nanoReel is a modern, portable SeeSnake diagnostic
reel and camera that has the flexibility and adaptability
to view small pipes, tubes, voids, and conduits� It
contains a unique, removable cable drum which makes
cleaning and replacing push cables convenient� Since
the nanoReel comes with a removable system cable, it
can be used with any SeeSnake camera control unit or
with the hand‑held micro CA‑300 inspection camera�
The nanoReel uses an advanced push cable design
and a proprietary small radius camera design which
allows camera inspection through pipes with very small
diameters, P‑traps, and very small radius bends which
conventional inspection systems often cannot inspect�
When using the nanoReel with an appropriate SeeSnake
control unit, the operator can connect an external line
transmitter and use a standard locator to line‑trace the
path of the nanoReel push cable in a pipe�
Specications
Table 1
SeeSnake nanoReel Specifications
Weight
:
with micro CA‑300
inspection camera
14�65 lb [6�6 kg]
without micro CA‑300
inspection camera
9�15 lb [4�1 kg]
Dimensions:
Length 13�25 in [33�6 cm]
Depth 6�6 in [16�7 cm)
Height 14�2 in [36 cm]
Frame diameter 12�75 in [32 cm]
Camera specifications:
Length 0�88 in [22�5 mm]
Diameter 0�61 in [15�5 mm]
Sonde
512 Hz
Lighting
6 LEDs
Resolution:
NTSC 656 × 492 pixels
PA L 768 × 576 pixels
Push cable:
Length 82 ft [25 m]
Diameter
0�25 in [6�3 mm]
Bend radius
1 in [25 mm]
Pipe capacity*
1 in [25 mm]
Operating environment:
Temperature
32°F – 115°F
[0°C – 46°C]
Storage temperature
−4°F – 158°F
[−20°C – 70°C]
Humidity 5% – 95% RH
Waterproof depth 225 ft [70 m]
* The nanoReel will traverse a 1 in [25 mm] straight
pipe, but its ability to go past 90‑degree turns will
depend on the material and construction of individual
pipes and joints� Test the material you intend to
inspect to ensure the camera can pass through turns
successfully� Some fittings in small diameter joints will
allow passage of the camera in only one direction�
Standard Equipment
• nanoReel
• Operator’s Manual
• Instructional DVD
• Ball Guides (two sizes)
