RIDGID micro CA-300 - Nanoreel Components; Icon Legend

6 – English
nano
TM
nanoReel Components
System Cable for
SeeSnake CCU
Push Cable Guide
Case Latch
Camera Clip
Camera Head
Front Case
Feet
Rear Case
Figure 1 – Front View (SeeSnake Configuration)
Push Cable
Removable
Push Cable
Drum
Case Latch Camera Head
Figure 2 – Inside Case
Figure 3 – Rear View (with the micro CA -300
inspection camera)
Icon Legend
Table 2
micro CA-300 Icons
Icon
Meaning
Return Key
Shutter Key
Select Key
Arrow Keys
Power Key
Rotate Image Key
Menu Key
Cord Wrap
micro CA‑300 Camera Monitor
micro CA‑300
Connector
Plug
Case Latch
System Cable for
micro CA‑300
Feet
Rear Case
Slip‑Ring Module
