Repair Parts
Parts List For RIDGID 10" Compound Miter Saw
Model No. MS10502
RIDGID parts are available on-line at www.ridgidparts.com
Figure 4
Always order by Part Number — Not by Key Number
* Standard hardware - may be purchased locally
WARNING: These items are important to the safety of this tool. Do not substitute common parts.
‡ CAUTION: See mechanical assembly caution below.
• WARNING: Uncontrolled spring release or misinstallation of these parts may create a hazard unless
repair is done by a qualified service technician. Repair service is available from authorized RIDGID Ser-
vice Center.
CAUTION: Mechanical Assembly, to qualified service technician.
1. Wear approved eye protection when working with coil spring including spring, arbor lock 823322.
2. Incorrect reassembly of torsion spring 823328 can cause an unsafe condition because cutting head fails
to rise fully to stop, or because spring fails through over-stress.
3. Improper reassembly of mechanisms controlling movement of lower guard 826039 can cause an unsafe
condition because guard fails to operate freely as cutting head is moved up and down.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
37429
826487-1
823300-1
823316-1
821421-3
9416390
826031
826481
826720
823303
827413
823304
Dust Elbow
Arm/Guard Asm
Washer Cup
Arbor Asm
Ring “O”
* Screw Pan Cr Ty “T” 10-32 x 5/8
Bumper Guard
Screw Lock Set 1/4-20 x 3/8
Bumper
Collar Blade
Blade Saw Carbide
Screw Blade
Key
No.
Part No. Description
13
14
15
16
17
18
19
20
21
22
826039
826765
820219-1
826026
821521-1
823840-3
823292
821521
823306-1
828364
‡ Guard Lower
Retainer Bearing
Screw Pan Cr Ty “TT”
1/4-20 x 3/8
Link Actuator
Screw Shoulder
Retainer Guard Asm
•‡ Spring Guard
Screw Shoulder
Bearing Cam
Bag Dust
