Repair Parts
Parts List For RIDGID 12" Compound Miter Saw
Model No. MS12502
RIDGID parts are available on-line at www.ridgidparts.com
Figure 1
Always order by part number - not by key number
* Standard Hardware Item - May be purchased locally.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
828102
141594-17
821063-6
827439
820244-6
828103
816755-10
826886
828104
827434
827438
826882
9421621
827449
823331
827879
827886
823361
828105
828116
60047
Fence Sliding
Screw Soc Cap 5/16-18 x 1
*Washer 8 x 16 x 1.2
Knob Fence
*ScrewPanHdM6x1.0x18
Fence Stationary
*Screw Pan Hd. M5 x 0.8-8
Plate Throat
Ta ble
Shaft Bevel Pivot
Indicator Bevel
Stop Bevel Index
*Screw Soc Cap
5/16-18 x 5/8
Screw Soc Set Lock
M8 x 1.25-16
Shoe Left
Plate Guard
Screw Sems M5-10
Shoe Base Rear
Base
Washer Spring
16.3 x 25 x 0.4
Washer .630 x 1 x 1/32
Key
No.
Part No. Description
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
–
823355
828106
140785-6
9421622
828040-1
828032
827886-1
828031
823356
828128
828029
821063-6
823335
823332
826885
823492
828109
828048
828119-1
SP6449
828050
Bolt Table Pivot
Arm Miter
*Lockwasher Int. Tooth 5/16"
*Screw Soc Cap
5/16-18 x 3/4
Screw Set Lock
M6 x 1.0-16
Knob Miter
Screw Sems M5-5
Plate Clamp Miter
Shoe Base Front
Grip Miter Index
Spring Miter Index
* Washer 8 x 16 x 1.2
Grommet Wrench
Shoe Right
Indicator Miter
Wrench Hex “L” 1/4
Table Extension
Clamp
Screw Sems M5-12
Owners Manual
Bag Asm Ext. Hardware
(Not Illustrated)
