Repair Parts
Parts List For RIDGID 12" Compound Miter Saw
Model No. MS12502
RIDGID parts are available on-line at www.ridgidparts.com
Figure 2 Upper and Lower Guards ‡
Always order by part number - Not by key number
* Standard Hardware Item - May Be Purchased Locally.
‡ CAUTION: See Mechanical Assembly Caution below.
• WARNING: Uncontrolled spring release of misinstallation of these
parts may create a Hazard unless repair is done by a qualified service
technician.
CAUTION: Mechanical Assembly, to qualified service technician.
1. Wear approved eye protection when working with coil springs
including spring, arbor lock 823402.
2. Incorrect re-assembly of torsion spring 828066 can cause an unsafe
condition because cutting head fails to rise fully to stop, or because
spring fails through over-stress.
3. Improper reassembly of mechanisms controlling movement of lower
guard 826878 can cause an unsafe condition because guard fails to
operate freely as cutting head is moved up and down.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
823351
816720
823348
828042
827886-2
821878
827498
827512
827516
823402
828101-1
823353
823404
823359
828045
828038
828040-1
827543
828119
816755-6
Screw Arbor
Washer Blade
Collar Blade
Blade
Screw Sems M5 -35
Screw Shoulder
10-32 x 7/8"
Sleeve Rubber
Lock Arbor
Cap Grip
•Spring
Arm Guard Upper
Plate Retainer Arbor Lock
Screw Flat Hd M5 x 0.8-6
Grommet Arbor Lock
Bag Dust
Elbow
Screw Soc. Set Lock
M6 x 1.0-16
Chute Sawdust
Screw Sems M5-25
*ScrewPanHdM5x0.8-16
Key
No.
Part No. Description
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
823360
820238-2
821862
821875-1
817449-1
820238-5
823340-1
820725-01
820732-2
826879
826878
816677
821873
826876
817449-1
809372-3
827409
828142
820732-1
820724-01
828141
Bumper Lower Guard
* Washer 6.5 x 11.8 x 1.6
Bearing
Screw Shoulder M6-14
Nut Hex Lock M6 x 1.0
* Washer 6.5 x 13 x 0.8
Link Actuator
Spacer 7 x 10 x 4
Washer 5.5 x 16 x 0.8
Retainer Guard
• Guard Lower
Spring Guard
Screw Shoulder 10-32x.50
Pivot Lower Guard
Nut Hex Lock M6 x 1.0
*ScrewPanHd10-32x1/2
Retainer Bearing
* Screw Flat Hd M6 x 1.0-13
* Washer 7.5 x 16 x 0.6
Screw Shoulder
M5 x 0.8-16
Washer 1/4 x 16 x 1
To Next Page
