13
5/16-18 x 3/4" Long
1/4-20 x 1" Long
Pan Head Screw (4)
Square Head Screw (4)
1/4-20 x 1-3/4" Long
Pan Head Screw (1)
#6-32 x 1/2 Pan Head Screw (4)
#10-32 x 7/8" Long
Pan Head Self Threading Screw (2)
1/4-20 x 1" Long
Slotted Cup Point Set Screw (1)
17/64" Flat Washer (5)
11/32" x 7/8" x 1/16"
5/16" Lockwasher (4)
1/4" Lockwasher (4)
Tee Nut (1)
5/16" Diam. Hex Nut (4)
1/4" Diam. Hex Nut (4)
1/4" Hex “L” Wrench (1)
3/16" Hex “L” Wrench (1)
Wrench (2)
Rip Scale Indicator (2)
Yellow Key (1)
1/4" U-Clip (1)
Twin Nut (2)
Table Clamp Assembly (2)
- Thumbscrew
- Square Nut
- Clamp Bracket
- Cup Washer
Flat Washer (4)
Assembly
