Riello 20034365 - B Appendix - Accessories (on Request)

32
20035512
GB
Output power regulator kit for modulating operation
With the modulating operation, the burner continually adapts the power to the request for heat, ensuring great stability for the parameter
controlled: temperature or pressure.
Two components should be ordered:
• the output power regulator to install on the burner;
• the probe to install on the heat generator.
Output power regulator with signal 4-20 mA, 0-10V
Two components should be ordered:
• the analogue signal converter;
• the potentiometer.
Potentiometer kit for the indication of load position
Long Head Kit
Spacer kit
Soundproofing chamber
Vibration reduction kit (for flame inversion boilers)
Parameter to be checked Probe Output Regulator
Adjustment field Type Code Type Code
Temperature - 100...+ 500°C PT 100 3010110
RWF40 3010414
Pressure
0...2.5 bar
0...16 bar
Output probe
4...20mA
3010213
3010214
Burner Potentiometer Analogue Signal Converter
RS 100/M Type Code Type Code
ASZ... 3010416 E5202 3010415
Burner Kit code
RS 100/M 3010416
Burner Kit code Standard head length
Head length obtained
with the kit
RS 100/M 3010260 250 mm 385 mm
Burner Kit code Thickness
RS 100/M 3010129 135 mm
Burner Kit code Type
Reduction of
noise average
RS 100/M 3010404 C4/5 10 [dB(A)]
Burner
Combustion
head
Kit code
RS 100/M
TC
3010202
TL
Appendix - Accessories (on request)
B
