Contents
Section Page
1
Information and general warnings 3
1.1 Information about the instruction manual 3
1.2 Guarantee and responsibility 3
2
Safety and prevention 4
2.1 Introduction 4
2.2 Personnel training 4
3
Technical description of the burner 5
3.1 Burner designation 5
3.2 Models available 5
3.3 Burner categories - Countries of destination 5
3.4 Technical data 6
3.5 Burner weight 6
3.6 Overall dimensions 6
3.7 Firing rates 7
3.8 Burner components 8
3.9 Burner equipment 9
3.10 Servomotor 9
4
Installation 10
4.1 Notes on safety for the installation 10
4.2 Handling 10
4.3 Preliminary checks 10
4.4 Operating position 11
4.5 Securing the burner to the boiler 11
4.6 Combustion head adjustment 13
4.7 Assembly of the gas train 15
4.8 Electrical wiring 16
4.9 Calibration of the thermal relay 17
5
Start-up, calibration and operation of the
burner
18
5.1 Notes on safety for the first start-up 18
5.2 Operations before start-up 18
5.3 Burner start-up 19
5.4 Burner ignition 19
5.5 Burner adjustment 19
5.6 Operation sequence of the burner 22
5.7 Burner flame goes out during operation 22
5.8 Stopping of the burner 22
5.9 Measuring the ionisation current 23
5.10 Checking the air and gas pressure on the com-
bustion head
23
5.11 Final checks (with burner operating) 23
6
Faults - Probable causes - Solutions 24
7
Maintenance 25
7.1 Notes on safety for the maintenance 25
7.2 Maintenance programme 25
7.3 Opening the burner 26
7.4 Closing the burner 26
A
Appendix - Electrical panel layout 27
B
Appendix - Accessories (on request) 32
C
Appendix - Firing rate on basis of air density 33
