INSTALLATION DESCRIPTION
Installation, start up and maintenance must be carried
out by qualified and skilled personnel.
All operations must be performed as described in the
technical handbook supplied with the burner.
The burner is set in the factory on standard calibration
(minimum output). If necessary adjustments can be made
on the basis of the maximum output of the boiler.
Head setting is easy and aided by a graduated scale; a
test point allows reading the air pressure in the
combustion head.
The air damper position can be adjusted without
removing the burner cover.
The maintenance position is easily carried out by hinge
that joins the body of burner to the flange.
Riello 40 GSD burners are fitted with an air pressure
switch which, in accordance with EN 676 standards,
can be adjusted by the installer using a graduated
selector, on the basis of the effective working conditions.
BURNER SETTING
MAINTENANCE
12
