V
IEWS OF THE
UPS
CONNECTIONS
Power connections: EXTERNAL BATTERY, INPUT, SEPARATE BYPASS (optional), OUTPUT
Connection for external synchronization signal
Connection for remote maintenance bypass command
Connection for external Battery Box temperature probe
