Technical description of the burner
3.3 Electrical data
Fan motor and pump motor IE3/NEMA PREMIUM EFFICIENCY
Tab. D
Model RLS 280/E RLS 310/E
Control circuit power supply V/Ph/Hz 120/1/60
Main power supply (+/- 10%) V/Ph/Hz 230-460/3/60 575/3/60 460/3/60 575/3/60
Fan motor rpm
HP
V
A
3510
5.5
230/460
12.4-6.2
3510
5.5
575
5.0
3540
10.2
230/460
24-12
3540
10.2
575
9.6
Pump motor rpm
HP
V
A
3515
2
230/460
5.6-2.8
3515
2
575
2.3
3515
2
230/460
5.6-2.8
3515
2
575
2.3
Ignition transformer Gas Pilot V1 - V2
I1 - I2
120 V - 1 x 8 kV
1.6 A - 20 mA
Electrical power consumption W 6250 6350 10060 10100
Electrical control circuit consumption W max 750
Total electrical consumption W 7000 7100 10810 10850
Electrical protection NEMA 3
Model RLS 410/E RLS 510/E
Control circuit power supply V/Ph/Hz 120/1/60
Main power supply (+/- 10%) V/Ph/Hz 460/3/60 575/3/60 460/3/60 575/3/60
Fan motor rpm
HP
V
A
3545
12.4
230/460
29/14.5
3545
12.4
575
11.6
3535
14.8
230/460
35.4/17.7
3535
14.8
575
14.2
Pump motor rpm
HP
V
A
3515
2
230/460
5.6/2.8
3515
2
575
2.3
3515
2
230/460
5.6/2.8
3515
2
575
2.3
Ignition transformer Gas Pilot V1 - V2
I1 - I2
120 V - 1 x 8 kV
1.6 A - 20 mA
Electrical power consumption W 11910 11950 13870 13950
Electrical control circuit consumption W max 750
Total electrical consumption W 12660 12700 14620 14700
Electrical protection NEMA 3
