Riello RLS 280/E - Electrode and Ignition Pilot Adjustment (RLS 310 - 410 - 510;E Model); Gas Butterfly Valve

20106891
22
GB
Installation
4.8 Electrode and ignition pilot adjustment (RLS 310 - 410 - 510/E model)
Place the electrode and the ignition pilot observing the dimensions
in Fig. 15.
4.9 Gas butterfly valve
If necessary, replace the gas butterfly valve.
The correct position is shown in Fig. 17 on page 23.
1 37/64"
Fig. 15
20123208
