Riello RTQ 91 3S - Page 7

7
GENERAL
0
3
0
6
0
9
0
3
2
1
12
46785
13
14
10
9
11
15
1 - Burner
2 - Flame inspection window with pressure
measurement / cooling valve
3 - Door
4 - Casing
5 - Central heating return
6 - Safety device fitting
7 - Instrument bulb/sensor sockets
8 - Central heating flow
9 - Flue gas pipes
10 - Turbulators
11 - Combustion chamber
12 - Flue gas exhaust
13 - Flue gas box
14 - Inspection window
15 - Condensate drain
RTQ 115 - 2400 3S
