Chapter 2 Front Panel Operations RIGOL
DG1000Z User’s Guide 2-95
Harmonic State Off
User-defined X0000000
Arb Waveform
Sample Rate
20MSa/s
DC Offset 0V
DC
Arb Waveform Mode Frequency
Built-in Arbitrary Waveform Sinc
Insret Waveform
Insert position
1
Insert Way Insert
Cycles 1
Points 8
High Level
2.5V
Low Level
-2.5V
Edit Points
Points 1
Voltage -2.5V
Edit Block
X1
1
Y1
-2.5V
X2
8
Y2 -2.5V
Modulation
Modulation Type
AM
AM Modulation
Modulation Source
Int
Modulating Waveform Shape Sine
Modulation Frequency 100Hz
Modulation Depth 100%
Carrier Waveform Suppression
Off
FM Modulation
Modulation Source Int
Modulating Waveform Shape Sine
Modulation Frequency 100Hz
Frequency Deviation
1kHz
PM Modulation
Modulation Source
Int
Modulating Waveform Shape Sine
Modulation Frequency 100Hz
Phase Deviation 90°
ASK Modulation
Modulation Source
Int
