Chapter 5 Specifications
Unless otherwise specified, all specifications can be guaranteed if the following two
conditions are met.
The generator is within the calibration period and has performed self-calibration.
The generator has been working continuously for at least 30 minutes under the
specified temperature (18℃~28℃).
All the specifications are guaranteed unless those marked with “typical”.
Channel 2 2 2
Maximum Frequency 25MHz 30MHz 60MHz
Basic waveforms Sine, Square, Ramp, Pulse, Noise
Built-in Arbitrary
Waveforms
160 kinds, including Sinc, Exponential Rise, Exponential
Fall, ECG, Gauss, HaverSine, Lorentz, Dual-Tone, etc.
Frequency Characteristics
Sine 1μHz to 25MHz 1μHz to 30MHz 1μHz to 60MHz
Harmonic 1μHz to 10MHz 1μHz to 10MHz 1μHz to 20MHz
Noise (-3dB)
25MHz
bandwidth
30MHz
bandwidth
60MHz
bandwidth
Arbitrary Waveform 1μHz to 10MHz 1μHz to 10MHz 1μHz to 20MHz
Resolution 1μHz
Accuracy
±1ppm of the settings, 18℃ to 28℃
Sine Wave Spectrum Purity
Harmonic Distortion
DC-10MHz (included): <-65dBc
10MHz-30MHz (included): <-55dBc
30MHz-60MHz (included): <-50dBc
Total Harmonic
Distortion
<0.075% (10Hz-20kHz, 0dBm)
Spurious
(non-harmonic)
Typical (0dBm)
≤10MHz: <-70dBc
>10MHz: <-70dBc+6dB/octave
Phase Noise
Typical (0dBm, 10kHz deviation)
10MHz: <-125dBc/Hz
