XII DG1000Z User’s Guide
Document Overview
Subjects in this Manual
Briefly introduces the appearance and
dimensions, front/rear panel and user interface
of DG1000Z.
Chapter 2 Front Panel Operations
Introduce the main functions and operation
methods of DG1000Z.
Chapter 3 Remote Control Briefly introduce how to control the DG1000Z
remotely.
Chapter 4 Troubleshooting List the possible failures or problems and their
solutions when using DG1000Z.
Provide the specifications of DG1000Z series.
Chapter 6 Appendix Provide the information about the options and
accessories list as well as warranty information
of DG1000Z.
Format Conventions in this Manual
1. Button:
The button at the front panel is denoted by the format of “Text Box + Button
Name (Bold)” in the manual, for example, Sine.
2. Menu:
The menu is denoted by the format of “Character Shading + Menu Word (Bold)”
in the manual, for example, Freq.
3. Connector:
The connector at the front or rear panel is denoted by the format of “Square
Brackets+Connector Name (Bold)” in the manual, for example, [Counter].
4. Operation Steps:
The next step of the operation is denoted by an arrow “” in the manual. For
example, Sine Freq represents pressing Sine at the front panel and then
pressing Freq.
