RIGOL Chapter 3 Remote Control
3-6 DG1000Z User’s Guide
3. Search device resource
Start up the Ultra Sigma and click
. The window as shown in figure
(a) is displayed. Click
and the software searches for the instrument
resources currently connected to the LAN and the resources found are displayed
at the right of the window as shown in figure (b). Click
to add it.
(a)
(b)
