Chapter 5 Specifications RIGOL
DG1000Z User’s Guide 5-3
Output Characteristics
Amplitude (into 50 Ω)
Range
≤10MHz: 1.0mVpp to 10Vpp
≤30MHz: 1.0mVpp to 5.0Vpp
≤60MHz: 1.0mVpp to 2.5Vpp
Accuracy
Typical (1kHz Sine, 0V Offset, >10mVpp, Auto)
±1% of setting ± 1mV
Flatness
Typical (Sine 2.5Vpp)
≤10MHz: ±0.1dB
≤60MHz: ±0.2dB
Units Vpp, Vrms, dBm
Resolution
0.1mVpp or 4digits
Offset (into 50 Ω)
Range (Peak ac+dc) ±5Vpk ac+dc
Accuracy ±(1% of setting+5mV+0.5% of amplitude)
Waveform Output
Impedance
50Ω (typical)
Protection
Short-circuit protection, automatically disable waveform
output when overload occurs
Modulation Characteristics
Modulation Type
AM, FM, PM, ASK, FSK, PSK, PWM
AM
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source Internal/External
Modulating Waveform
Sine, Square, Ramp, Noise, Arb
Depth
0% to 120%
Modulating Frequency
2mHz to 1MHz
FM
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source Internal/External
Modulating Waveform
Sine, Square, Ramp, Noise, Arb
Modulating Frequency
2mHz to 1MHz
PM
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source Internal/External
Modulating Waveform Sine, Square, Ramp, Noise, Arb
Phase Deviation
0° to 360°
Modulating Frequency
2mHz to 1MHz
ASK
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Source Internal/External
Modulating Waveform
Square with 50% duty cycle
Key Frequency
2mHz to 1MHz
