RIGOL Chapter 13 Specifications
DG4000 User's Guide
13-2
Sine Wave Spectrum Purity
Harmonic Distortion Typical (0dBm)
DC-1MHz: <-60dBc
1MHz-10MHz: <-55dBc
10MHz-100MHz: <-50dBc
100MHz-160MHz: <-40dBc
Total Harmonic
Distortion
<0.1% (10Hz-20kHz,0dBm)
Spurious
(non-harmonic)
Typical (0dBm)
≤10MHz <-65dBc
>10MHz <-65dBc+6dB/octave
Phase Noise Typical (0dBm, 10kHz deviation)
10MHz: ≤-115dBc/Hz
Signal Characteristics
Square
Rise/Fall Time Typical (1Vpp)
<8ns
Typical (1Vpp)
<10ns
Typical (1Vpp)
<12ns
Overshoot Typical (100kHz, 1Vpp)
<3%
Duty Cycle ≤10MHz: 20.0% to 80.0%
10MHz-40MHz: 40.0% to 60.0%
>40MHz: 50.0% (fixed)
Non-symmetry 1% of period +5ns
Jitter (rms) Typical (1MHz, 1Vpp, 50Ω)
≤5MHz 2ppm+500ps
>5MHz 500ps
Ramp
Linearity ≤1% of peak output (Typical, 1kHz, 1VPP, 100% Symmetry)
Symmetry 0% to 100%
Pulse
Period 25ns to 1000000s 40ns to
1000000s
66.7ns to
1000000s
Pulse Width ≥10ns ≥12ns ≥18ns
Leading/
Trailing Edge Time
≥5ns ≥7ns ≥11ns
