Rigol DG800 Pro Series - Front Panel Overview

4.2 Front Panel Overview
14
13
8
9
7
3
4
2
1
5
6
10
12
11
Figure 4.3 Front Panel
1
7-inch Touch Screen 8 Input Connector for the Signal
Measured by Counter
2 Output Mode Selection Area 9 Channel Output Control Area
3 Basic Waveform Selection Area 10 Align Key
4 Parameter Input Area 11 CH2 Output Connector
5 Quick Operation Key 12 CH1 Output Connector
6 Manual Trigger Key 13 USB HOST Interface
7 Counter Control Area 14 Power Key
Product Overview
