Document Overview
This manual gives you a quick overview of the front and rear panels, user interface as
well as basic operation methods of DG800 Pro series function/arbitrary waveform
generator.
TIP
For the latest version of this manual, download it from RIGOL official website ( www.rigol.com ).
Publication Number
QGB14100-1110
Format Conventions in this Manual
1. Key
The front panel key is denoted by the menu key icon. For example,
indicates the "Default" key.
2. Menu
The menu item is denoted by the format of "Menu Name (Bold) + Character
Shading" in the manual. For example,
Setup.
3. Operation Procedures
The next step of the operation is denoted by ">" in the manual. For example,
> Utility indicates first clicking or tapping and then clicking or tapping Utility.
Content Conventions in this Manual
DG800 Pro series function/arbitrary waveform generator includes the following
models. Unless otherwise specified, this manual takes the two-channel model DG852
Pro as an example to illustrate the functions and operation methods of DG800 Pro
series.
Model No. of Channels Sample Rate
Max. Output
Frequency
DG821 Pro 1 625 MSa/s 25 MHz
DG822 Pro 2 625 MSa/s 25 MHz
DG852 Pro 2 625 MSa/s 50 MHz
