Rigol DM3061 User Manual

RIGOL
© 2007 RIGOL Technologies, Inc.
User‟s Guide for DM3000 Series
1-36
To Choose Range Options
Use “manual” selection or “automatic” to choose measurement range. The
“automatic” allows the instrument to determine the most appropriate range while for
better performance choose the “manual” method.
Figure 1- 61 Choice Range Options Keys
Methods 1:
Use up and down direction keys to adjust the Range. Press Up to increase the range,
press Down to reduce the range.
Press key, to select the automatic method.
Methods 2:
Use the menu option keys to adjust the range as shown in the following Figure 1- 62.
Figure 1- 62 Choice Range Options Menu
Automatic
selection range
Increased range
Reduced range

Rigol DM3061 Specifications

General

Type	Digital Multimeter
Display	LCD
Max Voltage Measurement	1000 V
Max Current Measurement	10 A
Frequency Measurement	100 kHz
Data Logging	Yes
Connectivity	USB, RS232
Continuity Test	Yes
Diode Test	Yes
Capacitance Accuracy	1%
DC Voltage Range	100mV to 1000V
AC Voltage Range	100mV to 750V
DC Current Range	200 uA - 10 A
DC Current Accuracy	0.1%
AC Current Range	200 uA - 10 A
AC Current Accuracy	0.3%
Resistance Range	100Ω to 100MΩ
Frequency Range	10Hz to 100kHz
Temperature Range	-200 °C to 1350 °C
Temperature Accuracy	0.5%
Power Supply	100 V - 240 V
