RIGOL
© 2007 RIGOL Technologies, Inc.
User‟s Guide for DM3000 Series
5-11
Characteristics for DM305x
DC Characteristics
Accuracy Specifications (% of reading + % of range)
[1]
Function
Range
[2]
Test Current
or Burden
Voltage
Input
Impedance
1 Year
23±5
Temperature
Coefficient
0 to 18
28 to 55
DC
Voltage
400.000mV
10MΩ or>10GΩ
0.025 + 0.008
0.0015+0.0005
4.00000V
10MΩ or>10GΩ
0.025 + 0.006
0.0010+0.0005
40.0000V
10MΩ
0.025 + 0.006
0.0020+0.0005
400.000V
10MΩ
0.030 + 0.006
0.0020+0.0005
1000.00V
[4]
10MΩ
0.030 + 0.005
0.0015+0.0005
DC
Current
2.00000mA
<0.03V
0.050 + 0.070
0.0040+0.0070
20.0000mA
<0.3V
0.050 + 0.008
0.0040+0.0007
200.000mA
<0.3V
0.050 + 0.009
0.0040+0.0008
1.00000A
<0.3V
0.100 + 0.070
0.0100+0.0062
10.0000A
[5]
<0.6V
0.200 + 0.007
0.0100+0.0007
Resistance
[3]
400.000Ω
1mA
0.050 + 0.010
0.0030+0.0005
4.00000kΩ
100uA
0.015 + 0.006
0.0030+0.0005
40.0000kΩ
10uA
0.015 + 0.006
0.0030+0.0005
400.000kΩ
2uA
0.030 + 0.007
0.0030+0.0005
4.00000MΩ
200nA
0.060 + 0.010
0.0030+0.0005
100.000MΩ
200nA ||10MΩ
2.00 + 0.005
0.1500+0.0005
Diode Test
2.4000V
[6]
1mA
0.05 + 0.010
0.0050+0.0005
Continuity
2000Ω
1mA
0.05 + 0.010
0.0050+0.0005
