RIGOL Chapter 2 Performance Verification Test
2-4 DM3068 Performance Verification Guide
2V 20kHz Q ±1.2mV ±1.6mV ±1.8mV
2V 50kHz ±2.8mV ±3.2mV ±3.4mV
2V 100kHz ±12.6mV ±13.6mV ±13.6mV
2V 300kHz ±90mV ±90mV ±90mV
100mV 1kHz ±440μV ±650μV ±660μV
20.00000V 20V 10Hz ±76mV ±78mV ±78mV
20V 20kHz Q ±16mV ±22mV ±24mV
20V 50kHz ±30mV ±34mV ±40mV
20V 100kHz ±126mV ±136mV ±136mV
3.2V 300kHz ±228mV ±228mV ±228mV
200.0000V 200V 45Hz ±120mV ±200mV ±220mV
200V 20kHz Q ±120mV ±200mV ±220mV
200V 50kHz ±280mV ±340mV ±400mV
200V 100kHz ±1.26V ±1.36V ±1.36V
750.000V 320V 45Hz ±278mV ±449mV ±481mV
320V 20kHz Q ±278mV ±449mV ±481mV
320V 50kHz ±620mV ±759mV ±855mV
320V 100kHz ±2.36V ±2.52V ±2.52V
750V 10kHz Q ±450mV ±750mV ±825mV
Note
[1]
: The AC filter is set to "Slow".
Note
[2]
: Q marks the optional quick test points.
3. The AC current gain test procedures
(1) Make sure you have carefully read the "Test Conditions".
(2) Connect the input terminals of the multimeter with the calibrator.
(3) Test the ranges specified in Table 2-4. Set the AC filter to "Slow" and turn off all the math
operations.
(4) Input the signals specified in Table 2-4 using the calibrator and compare the test results
with the limits in the table (make sure the output of the calibrator is built adequately).
Table 2-4 AC current gain test items
Range
[1]
Test
Signal
Input
Frequency
Quick
Test
[3]
Allowable Error Range
24 hours 90 days 1 year
200.0000μA
200μA 1kHz Q ±420nA ±420nA ±420nA
200μA 5kHz ±420nA ±420nA ±420nA
200μA 10kHz ±2.1μA ±2.1μA ±2.1μA
2.000000mA
2mA 1kHz Q ±3.2μA ±3.2μA ±3.2μA
2mA 5kHz ±3.2μA ±3.2μA ±3.2μA
2mA 10kHz ±9μA ±9μA ±9μA
20.00000mA 20mA 1kHz Q ±42μA ±42μA ±42μA
20mA 5kHz ±42μA ±42μA ±42μA
20mA 10kHz ±210μA ±210μA ±210μA
200.0000mA 200mA 1kHz Q ±280μA ±280μA ±280μA
