Chapter 2 Performance Verification Test RIGOL
DM3068 Performance Verification Guide
200mA 5kHz ±280μA ±280μA ±280μA
200mA 10kHz ±900μA ±900μA ±900μA
10mA 10kHz Q ±520μA ±520μA ±520μA
2.000000A 2A 1kHz Q ±4.2mA ±4.2mA ±4.2mA
2A 5kHz ±4.2mA ±4.2mA ±4.2mA
10.00000A
[2]
10A 1kHz ±23mA ±25mA ±25mA
Note
[1]
: The AC filter is set to "Slow".
Note
[2]
: For continuous currents greater than DC 7A or AC RMS 7A, close the circuit for 30 seconds and then open the
circuit for 30 seconds.
Note
[3]
: Q marks the optional quick test points.
4. The frequency gain test procedures
(1) Make sure you have carefully read the "Test Conditions".
(2) Connect the input terminals of the multimeter with the calibrator.
(3) Select the range according to Table 2-5 and turn off all the math operations.
(4) Input the signals specified in Table 2-5 using the calibrator and compare the test results
with the limits in the table (make sure the output of the calibrator is built adequately).
Table 2-5 Frequency gain test items
Signal
Effective Value
Signal
Frequency
Quick
Test
[1]
Range
Allowable Error Range
24 hours 90 days 1 year
20mV 98Hz 200mV ±4.9mHz ±5.88mHz ±6.86mHz
200mV 500kHz Q 2V ±25Hz ±30Hz ±35Hz
Note
[1]
: Q marks the optional quick test point.
5. The capacitance gain test procedures
(1) Make sure you have carefully read the "Test Conditions".
(2) Switch to the capacitance measurement function and select a range listed in Table 2-6.
(3) Connect one end of the shielded cable to the input terminal of the multimeter and leave the
other end free; then, execute "REL" operation.
(4) Connect the other end of the shielded cable to the calibrator.
(5) Input the signals specified in Table 2-6 using the calibrator and compare the test results
with the limits in the table (make sure the output of the calibrator is built adequately).
(6) Repeat steps (2), (3), (4) and (5) to finish the test.
Table 2-6 Capacitance test items
Range
[1]
Test Signal Quick Test
[2]
Allowable Error Range
1 year
2.000nF 2nF Q ±90pF
20.00nF 20nF ±260pF
200.0nF 200nF ±2.6nF
2.000uF 2uF ±26nF
20.00uF 20uF ±260nF
