6
Using the Built-in Help System
Tap > Help to enter the help interface as shown in the figure below. The built-in
help system can help you learn about the instrument, obtain a list of help topics, and
update instrument firmware.
Figure 6.1 Help Interface
About
Tap About to view the system information of the instrument, including the instrument
model number, serial number, firmware version, and calibration time.
Help
Tap
Help to view the help information for front-panel keys or menu keys. You can tap
a function key topic at the left side to obtain a detailed description of its function.
Upgrade
Tap
Upgrade to access the software upgrade interface. You can read the USB storage
device and tap
Upgrade to update instrument firmware. You can also connect the
instrument to network and then tap Remote to download the firmware upgrade file
( is displayed in the notification area in the process). After the file is downloaded,
the instrument restarts in 2 seconds and starts to upgrade.
Others
Tap
Others to enter the interface in which you can obtain the following help topics:
• View the last displayed message
• View remote command error queue
Using the Built-in Help System
20
