Chapter 2 Front Panel Operations RIGOL
DP800 User’s Guide 2-35
Table
Display each group of voltage, current and power of the current channel in
the record file opened in table form.
You can view the analysis results of the specified channel by
switching the current channel.
You can view the specified group of data by setting the "Current
Time".
Current Time
You can quickly locate each group of data of the record file opened
between the start time and end time by setting the current time. If the
current display mode is figure, the interface will locate the current data (the
voltage, current or power corresponding to the "Current Time" is displayed
above the figure) using a cursor line in the color corresponding to the
current channel.
Press Cur Time and use the numeric keyboard or the left/right direction
key and knob to set the desired value. The range is from the start time to
the end time.
