RIGOL Chapter 2 Constant Voltage Tests
DP800 Performance Verification Manual
2-18
Notes:
 For the single channel model with multiple ranges of DP800 series (DP811A),
please first select a range and set the corresponding parameters of this range
in step 3 and then perform step 4 to step 6 to test the transient response time
of this range. Then, repeat step 3 to step 6 to test the transient response time
of the other range.
 For the channels that support the Sense function of DP800 series, please
connect DP800, AC power supply, electronic load and oscilloscope according
to Figure 2-2
and turn on the Sense function of the channel after selecting the
current channel in step 3.
Test Record Forms:
Table 2-17 DP831A Transient Response Time Test Record Form
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification <50μs
DP831A
Setting
Voltage 8V 30V -30V
Current 5.3A 2.1A 2.1A
Electronic
Load Current
Setting
CCDH1 5A 2A 2A
CCDH2 2.5A 1A 1A
Measurement
Result
t
Table 2-18 DP832A Transient Response Time Test Record Form
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <50μs
DP832A
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Electronic
Load Current
Setting
CCDH1 3A 3A 3A
CCDH2 1.5A 1.5A 1.5A
Measurement
Result
t

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
