RIGOL Chapter 5 Disassembly and Assembly
Service Guide for DS1000E, DS1000D Series
5-2
Notices
Notices:
 Don’t disassemble the product except the work needed.
 Disassemble only can be done by qualified person.
 Cut the power before disassembling.
 Take ESD glove under disassembling.
 Use proper tools and follow the disassembly sequence.
 Prevent metallic parts from transfiguration and avoid being scratched when
disassembling.
Required tools:
 TORX drivers (T6, T10, T20)
 BNC sleeve
WARNING
Before disassembling, please make sure the power has been cut off. The
operator should be trained or had related qualification.
!
