Rigol DS1052D Service Guide

RIGOL Chapter 7 Replaceable Parts
Service Guide for DS1000E, DS1000D Series
7-2
Table 7-1 Replaceable parts list
No.
Name
Specification
1
Big Knob
2
Small Knob
3
Panel
4
LCD
Color Screen: FG050600ANNNA-01
5
Metallic Tank Body
6
Rubber Button
7
BNC Nut
BNC Nut
8
BNC Lock Spacer
BNC Lock Spacer
9
Encoder
10
Keyboard
11
Bolt
0.1*0.3inch Hexagon Bolt, British
system
12
Fan
AFB0612LC-714
13
Large Terminal
14
Small Terminal
15
BNC
16
Cooling Plate
Aluminum
17
LA Board
18
LA Interface
19
RS-232 Interface
20
Power Jacket
21
USB Host Interface
22
Mainboard
RDSB1003
23
USB Device Interface
24
Power Switch Cap
25
Upper Metallic Cover
26
Power Interface
27
Power Supply
28
Power Board
RDSB1001
29
Rear Metallic Cover
30
Female ScrewLock
M3*7/ DB9 bolt, British system
31
Front Trestle
32
Rear Trestle
33
Handle
34
Cover
